Description
Ref.:	26214-KA036
Huari No.:	HRK9944
Name:	Brake Shoe Set
Unit:	SET
Price:
Rear Axle Brake System : SUMITOMO Diameter : 180 mm Width : 25 mm

Model	Engine			Type	CYL	year
SUBARU REX III					6/89 - 3/92
REX III 0.5	EN05	547	38	Hatchback	4	6/89 - 7/90
REX III 0.5 4WD	EN05	547	38	Hatchback	4	6/89 - 7/90
REX III 0.5 Kompressor	EN05	547	61	Hatchback	4	6/89 - 7/90
REX III 0.8	EN08	758	42	Hatchback	4	6/89 - 3/92
SUBARU REX II					8/82 - 6/89
REX II 700	EK42	665	37	Hatchback	2	8/82 - 6/89
SUBARU VIVIO					3/92 - 0/95
VIVIO 660 4WD	EN07E	658	44	Hatchback	4	3/92 - 0/95
SUZUKI (CHANGHE) WAGON R (CH_)					1/01 - 9/05
WAGON R (CH_) 1.4	K14B	1372	91	MPV	4	9/05 - 3/06
WAGON R (CH_) 1.0	F10A	970	46	MPV	4	4/02 - 7/04
WAGON R (CH_) 1.0	K10A	996	65	MPV	4	6/00 - 7/04
WAGON R (CH_) 1.1	DA465Q	1051	50	MPV	4	1/03 - 7/04
WAGON R (CH_) 1.2	K12A	1171	69	MPV	4	1/01 - 9/05

Application

SUBARU REX KH3 660 90' 3-92' 2
SUBARU REX KP4 660 90' 3-92' 2
SUBARU REX KH4 660 90' 3-92' 2
SUBARU REX KH2 550 89' 6-90' 3
SUBARU REX KH1 550 89' 6-90' 3
SUBARU REX KG2 550 87' 2-89' 5
SUBARU REX KG1 550 F 86' 12-89' 5
SUBARU REX KG1 550 F 86' 12-89' 5
SUBARU REX KP3 660 90' 3-92' 2
SUBARU VIVIO KK3 660 92' 3-98' 9
SUBARU VIVIO KW4 660 92' 3-98' 9
SUBARU VIVIO KW3 660 92' 3-98' 9
SUBARU VIVIO KY3 660 93' 3-95' 9
SUBARU VIVIO KK4 660 92' 3-98' 9
SUBARU REX COMBI KN2 550 F 86' 11-89' 5
SUBARU REX COMBI KP2 550 89' 6-90' 3
SUBARU REX COMBI KN2 550 F 86' 11-89' 5
SUBARU REX COMBI KN1 550 F 86' 11-89' 5
SUBARU REX COMBI KN1 550 F 86' 11-89' 5
SUBARU REX COMBI KP1 550 89' 6-90' 3
SUBARU PLEO RV1 660 98' 10-
SUBARU PLEO RV2 660 4WD 98' 10-
SUBARU PLEO RA2 660 4WD 98' 10-
SUBARU PLEO RA1 660 98' 10-

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
