Description
Ref.:	04495-04010
Huari No.:	HRK2378
Name:	Brake Shoe Set
Unit:	SET
Price:
Rear Axle Diameter : 254 mm Width : 50.5 mm

Model	Engine			Type	CYL	year
TOYOTA HIACE IV Box (_H1_, _H2_)					9/06 - /
HIACE IV Box (LXH1_, RZH1_, LH1_) 2.5 D-4D (KLH12_, KLH22_)	2KD-FTV	2494	117	Box	4	9/06 - /
HIACE IV Box (LXH1_, RZH1_, LH1_) 2.5 D-4D 4WD (KLH28_)	2KD-FTV	2494	117	Box	4	9/06 - /
HIACE IV Box (LXH1_, RZH1_, LH1_) 2.5 D-4D (KLH12_, KLH22_)	2KD-FTV	2494	95	Box	4	9/06 - /
TOYOTA HIACE V Box (TRH2_, KDH2_)					1/05 - /
HIACE V Box (TRH2_, KDH2_) 2.5 D-4D	2KD-FTV	2494	95	Box	4	9/06 - /
HIACE V Box (TRH2_, KDH2_) 2.7 VVTi (TRH201, TRH221)	2TR-FE	2694	151	Box	4	1/05 - /

Application

TOYOTA HIACE KDH220K 2500 05' 1-
TOYOTA HIACE KDH205V 2500 04' 8-
TOYOTA HIACE KDH200K 2500 04' 8-
TOYOTA HIACE KDH200V 2500 04' 8-
TOYOTA HIACE TRH226K 2700 05' 1-
TOYOTA HIACE TRH224W 2700 05' 1-
TOYOTA HIACE TRH229W 2700 05' 1-
TOYOTA HIACE TRH211K 2700 05' 1-
TOYOTA HIACE TRH223B 2700 05' 1-
TOYOTA HIACE TRH219W 2700 04' 8-
TOYOTA HIACE TRH214W 2700 04' 8-
TOYOTA HIACE KDH227B 2500 05' 1-
TOYOTA HIACE KDH222B 2500 05' 1-
TOYOTA HIACE KDH225K 2500 05' 1-
TOYOTA HIACE TRH228B 2700 05' 1-
TOYOTA HIACE REGIUS KDH220K 2500 04' 1-
TOYOTA HIACE REGIUS KDH225K 2500 04' 1-
TOYOTA HIACE REGIUS TRH221K 2700 04' 1-
TOYOTA HIACE REGIUS TRH226K 2700 04' 1-
TOYOTA HIACE REGIUS KDH205V 2500 04' 1-
TOYOTA HIACE REGIUS KDH200V 2500 03' 8-
TOYOTA HIACE REGIUS TRH200K 2000 03' 8-
TOYOTA HIACE REGIUS TRH200V 2000 03' 8-
TOYOTA HIACE REGIUS KDH200K 2500 03' 8-
TOYOTA TACOMA 2005-

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
